4.0mm Wire Diameter Gabion Retaining Wall For Riverbank Protection

Brand Name : KN

Model Number : gabion

Certification : CE ISO SGS COC PVOC

Place of Origin : CN

MOQ : 100 pc

Price : USD 13-20

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 1000 pc per day

Delivery Time : 15 work days

Packaging Details : pallet

Product Name : 2.7mm Wire Diameter Plain Weave Gabion Basket for Riverbank Protection

Key Words : Gabion

Surface Treatment : Hot-dipped Galvanized

Processing Service : Bending, Custom Sizes

Hole Shape : Hexagonal

Size : 2x1x1m 3x1x1m 4x1x1m

Stock : Have Large Stock

Material : Galvanized Steel Wire

Contact Now

4.0mm Wire Diameter Gabion Wall Cost Per Metre For Riverbank Protection

Product Overview

Gabion Wall are manufactured in accordance with and meet the guidelines of ASTMA975-97. The stone fill material used for filling the gabion units is clean, hard stone with pieces ranging from 4 – 8 inches on the greatest dimension.

Key Features

  • Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
  • Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
  • Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
  • Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)
  • Advantage
    High Zinc Rate
    Selvedge wire
    3.0-4.0 mm
    Weaving type
    Durable Three Normal Twist

Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

  • Civil Engineering: Riverbank stabilization, highway embankments
  • Architecture: Retaining walls, sound barriers, decorative façades
  • Disaster Prevention: Flood control barriers, landslide mitigation systems
  • Mining: Tailings dam reinforcement, slope retention

Customization Services

  • Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
  • Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
  • Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
gabion specifications Mesh hole modle
8x10cm 6x8cm
Length(m) Width(m) Height(m) Galvanized or PVC coated Galvanized or PVC coated
Mesh diameter Zinc Mesh diameter Zinc
2 1 1 2.7mm >245g/m² 2.0mm >215g/m²
3 1 1 Side wire diameter Zinc Side wire diameter Zinc
4 1 1 3.4mm >265g/² 2.7mm >245g/m²
6 1 1 Binding wire diameter of 2.7m Binding wire diameter of 2.0m

Packaging Details
pallet
large gabion in stock,fast shipping
Gabion Mesh Manufacturer, Your reliable Project Partner.
Factory Price,Reliable Quality, Create Excellent Project !
Strict Quality Control:
1. During and after production, 3 QC staffs with more than 5 years experience inspect products in random.
2. National accredited laboratory with CNAS certificates
3. Acceptable inspection from third party appointed/paid by buyer,

Port
xin gang , tianjin

Selling Units:
Single item

Single package size:
50X50X5 cm

Single gross weight:
15.000 kg

4.0mm Wire Diameter Gabion Retaining Wall For Riverbank Protection4.0mm Wire Diameter Gabion Retaining Wall For Riverbank Protection
